Product Details
This Whiteline Front Sway Bar Link Kit fits the 1970-1973 Nissan 240Z. Position: front. The part number is W23836. In the box: 8 bushings, 2 tubes, 2 bolts, 8 washers, 2 nuts, and grease.
A sway bar link is the short rod that ties each end of the front sway bar to the suspension. Whenever the body leans, the link carries that motion into the bar, so any slop, flex, or wear in it is slop in the whole roll-control system.
Installation is rated moderate, with about 1 hour of work listed. No alignment is needed afterward. Other Whiteline parts we list for the 240Z: Tie Rod Boot Kit.
Features
- Grease: Moly grease is supplied to prolong the life of the parts.
- Bushing compound: The bushing material stands up to oil, grease, ozone, and weather.
- Self-lubricating: Internal grease reservoirs keep the bushing lubricated as it works.
- Bushing material: Made of polyurethane, which resists deflection better than soft rubber.
- Easy to fit: Designed so the install needs no specialized skills or tools.
- Install guide: Step-by-step installation instructions come with it.
Specifications
| Part Number | W23836 |
| Part Name | Sway Bar Links |
| Vehicle | 1970-1973 Nissan 240Z |
| Drivetrain | RWD |
| Chassis Code | S30 |
| Bolt Thread Diameter | 10 mm |
| Bushing Material | Polyurethane |
| Grade Type | Regular |
| Installation Difficulty | Moderate |
| Installation Time (hrs) | 1 |
| Kit Contents | 8 Bushings, 2 Tubes, 2 Bolts, 8 Washers, 2 Nuts, Grease |
| Length | 152 mm |
| Vehicle Placement | Front |
| Wheel Alignment Required | No |
| Notes | - |
