Product Details
This Whiteline Front Lower Inner Rear Control Arm Bushing Kit fits the 1992-1994 Mazda 323. The kit contains 2 bushings and 2 tubes. It is listed for the BG chassis. Part number W51263. Placement: front.
Every time the wheel moves, the control arm swings on its bushings. When they are soft or worn, the arm shifts under load, the alignment changes as the car moves, and steering and braking feel less precise. A stiffer bushing cuts that unwanted movement while still letting the arm pivot freely. The polyurethane used here deflects much less than the original rubber under the same load.
Installation is rated difficult, with about 2.5 hours of work listed. Plan on a wheel alignment afterward. Working on the same car? We also list 12mm Adjustable Front Camber Bolts, Front Sway Bar Washer Kit, and Front Strut Tower Brace Quick Release Kit for the Mazda 323.
Features
- Grease: Moly grease is supplied to prolong the life of the parts.
- Material: The part is made of polyurethane.
- Bushing compound: Oil, grease, ozone, and weather do not break down the synthetic elastomer used in the bushings.
- Easy to fit: Designed so the install needs no specialized skills or tools.
- Self-lubricating: Grease reservoirs inside the bushing feed lubrication as it moves.
- Install guide: Whiteline packs an install guide with it.
Specifications
| Part Number | W51263 |
| Part Name | Control Arm Bushings |
| Vehicle | 1992-1994 Mazda 323 |
| Chassis Code | BG |
| Bushing 1 Inner Diameter | 18.2 mm |
| Bushing 1 Outer Diameter | 45.2 mm |
| Bushing Quantity | 2 Bushings |
| Grade Type | Regular |
| Installation Difficulty | Difficult |
| Installation Time (hrs) | 2.5 |
| Kit Contents | 2 Bushings, 2 Tubes |
| Material | Polyurethane |
| Mounting Hardware Included | No |
| Vehicle Placement | Front |
| Wheel Alignment Required | Yes |
| Notes | - |
