Product Details
This Whiteline Front Lower Inner Forward Control Arm Bushing Kit fits the 2002-2006 Acura RSX (DC5). Part number W53410. Whiteline's note for this fit: Standard replacement. In the box: 2 shell bushings and an install guide. It goes on the front of the vehicle.
A control arm bushing is the pivot where the arm joins the chassis or the wheel carrier. Factory rubber is chosen for quiet and comfort, so it squashes under braking, acceleration, and cornering and lets the arm move more than it should. A firmer replacement keeps the arm where it belongs, which steadies the alignment and gives the car a more consistent feel. Polyurethane resists deflection far better than the soft rubber it replaces.
Expect a difficult job of about 2.5 hours. Get the car aligned once it is back on the ground. To go with it on the Acura RSX, see Rear Sway Bar Link, Front and Rear Sway Bar Kit, and 16mm Adjustable Front Camber Bolts.
Features
- Bushing material: Polyurethane is firmer than the factory rubber, so it deflects less under load.
- Material: Built from polyurethane.
- Self-lubricating: Internal grease reservoirs keep the bushing lubricated as it works.
- Install guide: Whiteline packs an install guide with it.
- Bushing compound: The elastomer formulation is chosen to shrug off oil, grease, ozone, and the elements.
Specifications
| Part Number | W53410 |
| Part Name | Control Arm Bushings |
| Vehicle | 2002-2006 Acura RSX |
| Chassis Code | DC5 |
| Bushing 1 Inner Diameter | 14.3 mm |
| Bushing 1 Length | 63 mm |
| Bushing 1 Outer Diameter | 65 mm |
| Bushing 2 Inner Diameter | 14.3 mm |
| Bushing 2 Length | 63 mm |
| Bushing 2 Outer Diameter | 65 mm |
| Bushing Color | Black |
| Bushing Material | Polyurethane |
| Bushing Quantity | 2 |
| Grade Type | Regular |
| Installation Difficulty | Difficult |
| Installation Time (hrs) | 2.5 |
| Kit Contents | 2 Shell Bushings, Install Guide |
| Material | Polyurethane |
| Mounting Hardware Included | No |
| Outside Diameter | 65 mm |
| Vehicle Placement | Front |
| Wheel Alignment Required | Yes |
| Notes | Suits 65mm OD - Standard replacement |
