Product Details
The VERA 8 Solenoid Valve Unit is the four-corner manifold, giving each corner its own fill and dump solenoid so the car can be leveled corner by corner rather than front and rear in pairs.
Eight solenoids rated to 180 PSI sit in a single block with push-to-connect fittings and a wiring harness, which keeps a four-corner install to one mounting point and one plug. It is the manifold to specify for independent corner control, and the service replacement for an existing VERA four-corner system.
Features
- Independent four-corner control from a single manifold block
- Eight solenoids rated to 180 PSI
- Push-to-connect fittings, no thread sealant needed
- Wiring harness included
- Available in 1/4 inch and 3/8 inch port sizes
Specifications
| Part Number | VA-PBK814 (1/4"); VA-PBK838 (3/8") |
| Part Name | VERA 8 Solenoid Valve Unit |
| Configuration | Four corner, eight solenoid |
| Pressure Rating | 180 PSI |
| Fittings | Push-to-connect |
| Harness | Included |
| Notes | Order the port size that matches your existing air line. |
