Product Details
The Bilstein SMX Series shock absorber is sold for custom and motorsport builds. There is no vehicle lookup here: you select on dimension, mounting, and the damping you want.
The monotube design is what separates these. A single high-pressure gas chamber keeps the oil from aerating, so damping stays consistent as the unit heats up instead of fading away.
Features
- Stock mount design for GM metric chassis applications
- 46mm piston design for maximum damping control
- A wide range of valving choices available for endless tuning combinations
Specifications
| Part Number | 24-296908 |
| Part Name | Shock Absorber |
| UPC | 651860847696 |
| Adjustable Damping | Non-Adjustable |
| Body Design | Stock Mount Smooth Body |
| Body Material | Steel |
| Boot Included | No |
| Collapsed Length | 12.95 in. (329mm) |
| Compression @ 10"/sec | 225 |
| Extended Length | 21.02 in. (534mm) |
| Finish | Black Paint |
| Internal Design | Monotube |
| Lower Mount Type | Eye |
| Piston Diameter | 46mm |
| Piston Type | Linear |
| Vehicle Placement | Rear |
| Rebound @ 10"/sec | 225 |
| Segment | Motorsports |
| Series | SMX Series |
| Shaft Diameter | 11mm |
| Spring Seat Included | No |
| Stroke/Travel Length | 8.07 in. (205mm) |
| Upper Mount Type | Bar Pin |
