Moton Suspension

|

SKU: M 503 014S

Moton Suspension 3 Way Motorsport Coilovers (True Coilover) for 2001-2004 Chevrolet Corvette 5.7 V8 (C5 Z06)

$7,650.00

MSRP $8,500.00 You save $850.00

Ask a question
Built to Order

Authorized DealerGenuine parts & warranty
20+ Years in BusinessTrusted since 2005
Free USA ShippingOn orders $250+
Best Price GuaranteeWe’ll match or beat it
Fitment Notes

All fitment information on our website is provided by the manufacturer. It is the customer's responsibility to thoroughly read the product description and confirm fitment before placing an order and proceeding with installation.

Unless specified otherwise, all suspension products are designed for 2WD vehicles only. Any notes or descriptions related to electronic damping systems (EDC, DDS, etc.) apply strictly to vehicle fitment. Aftermarket coilovers are not compatible with OEM electronic damping control systems unless explicitly stated.

*Product images may not represent the actual SKU.

Handling Time

All handling times are estimates and may change at any time.

  • In Stock: 1 business day
  • Out of Stock: 4-6 weeks
  • Custom-Builds: 4-6 weeks
  • Special Order: 4-6 weeks
30-Day Returns

Not quite right? No problem — we offer hassle-free 30-day returns on eligible items. A few exclusions apply.

More Information

2-Year Manufacturer Warranty

AST Suspension guarantees the Customer that when used normally and correctly, the Products are free from defects with regard to their material or workmanship. In the event that the Product is nevertheless defect, the Customer who is a Consumer may invoke the guarantee scheme which he/it is entitled to under the Dutch Consumer Sales Act [wet inzake consumentenkoop]. For other Customers, a warranty period of two years will apply. In no event shall any warranty apply for Products used for abnormal uses such as motor sport and/or auto sport and all its various disciplines.

More Information

Product Details

The Moton 3 Way Motorsport suspension for the 2001-2004 Chevrolet Corvette (C5 Z06) is designed for the professional racer. This ultimate suspension system is by far the finest quality and best handling suspension system on the market today.

Featuring remote reservoirs for superior fluid temperature control, quick release hydraulic lines (on most models) for easy installation, separate compression and rebound damper valving adjustment and height adjustable spring perches, this kit is beyond the more common coilover systems on the market. If your driving can benefit for the ultimate in suspension tuning, then this kit is for you.

Benefits

  • Improved platform stability
  • Improved traction, higher grip level
  • Improved curb stone and bumpy track control
  • Improved tire wear over the complete race distance
  • Easy to adjust and work with
  • Every single adjustment done is very noticeable to the driver
  • Proven reliability
  • Rebuildable/Revalveable

Features

  • Separate high speed bump (15 positions), low speed bump (6 positions) and rebound (15 positions) adjustments
  • Unique blow off valve system in canister to totally control curb stones and bumpy track conditions
  • Large piston rod diameter for more fluid displacement
  • Adjustable gas pressure for added lifting force
  • Large main piston for quick response
  • No preloaded valve stacks needed for low speed damping control
  • Swivel banjo hoses for easy installation of remote reservoirs
  • DDP (double digressive pistons) are available as an option
    • Double Digressive Pistons are recommended for use on the non-driven wheels
    • 4WD/FWD vehicles: DDP for both rear axle struts/shocks
    • RWD vehicles: DDP for both front axle struts/shocks
Specifications
Part Number M 503 014S
Part Name Moton 3 Way Motorsport Coilovers
Vehicle 2001-2004 Chevrolet Corvette
Placement Front & Rear
Chassis Code C5 Z06
Drivetrain RWD
Damping Adjustment 3-Way
Ride-Height Adjustable Yes
Top Mounts - Front Not available
Top Mounts - Rear Not available
Notes
  • Vehicle note: Coupe.
  • System: Alloy front, QD RR and CO rear.
  • Coil springs are included.
  • Adjustable droplinks are not needed.
  • Double digressive pistons (DDP) are not included but are available.
  • Quick disconnect couplings are included (rear only).

Vehicle fitment

This product fits the vehicles listed below.

YearMakeModelNotes
2001ChevroletCorvette
2002ChevroletCorvette
2003ChevroletCorvette
2004ChevroletCorvette
