Product Details

The Function and Form Type 4 Coilovers for the 2009-2017 Volvo XC60 (P3) are the brand's premium coilover system, built around an inverted monotube damper. These Volvo XC60 coilovers lower the car and keep the damping smooth and controlled.

Also branded Function & Form / F2 Suspension, the Type 4 uses a large inverted piston and long-stroke design to add travel, cut unsprung weight, and keep damping consistent when you drive hard. 1-Way adjustable rebound and compression and full ride height adjustment come in a bolt-on, preload-ready kit. Backed by a 24-month warranty with free U.S. shipping on orders over $250.

Features

  • Premium full-bodied coilover kit built around an inverted monotube damper for OE-plus refinement
  • Large 40mm inverted piston increases damper strength and reduces unsprung weight for crisper response
  • Long-stroke design adds suspension travel for a smooth, controlled ride in any condition
  • 1-Way adjustable rebound and compression to match your vehicle, road and driving style
  • Optimized heat dissipation keeps damping consistent during hard or sustained driving
  • Ride height adjustable from the lower mount, independent of spring preload
  • Camber top plates available or included for select MacPherson-strut vehicles
  • Hardware included. Backed by a 24-month limited warranty against manufacturer defect
Specifications
Part Number 45801209
Part Name Function and Form Type 4 Coilovers
Vehicle 2009-2017 Volvo XC60
Drivetrain FWD/AWD
Chassis Code P3
Adjustment Type 1-Way
Ride-Height Adjustable Yes
Top Mounts - Front Included
Top Mounts - Rear Included
Suspension Design - Front True Coilover
Notes Finish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles

Vehicle fitment

This product fits the vehicles listed below.

YearMakeModelDrivetrainNotes
2009VolvoXC60FWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2009VolvoXC60AWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2010VolvoXC60FWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2010VolvoXC60AWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2011VolvoXC60FWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2011VolvoXC60AWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2012VolvoXC60FWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2012VolvoXC60AWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2013VolvoXC60FWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2013VolvoXC60AWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2014VolvoXC60FWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2014VolvoXC60AWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2015VolvoXC60FWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2015VolvoXC60AWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2016VolvoXC60FWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2016VolvoXC60AWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2017VolvoXC60FWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
2017VolvoXC60AWDFinish: Chrome/Red; Hardware included; Camber top plates available or included for select MacPherson-strut vehicles
