Product Details
The Cusco Sport R Coilovers for the 2015-2021 Subaru WRX STI (VAF) deliver race-grade monotube performance with pillow ball upper mounts, inverted front struts, and competition-specification damper valving. Aggressive 14 Kg/mm front and 16 Kg/mm rear spring rates with 24-level rebound control prepare the VAF for time attack and endurance racing.
The VAF STI's symmetrical AWD and EJ25T turbo make it a formidable track weapon when properly suspended. The Sport R's stiff spring rates control drivetrain mass during hard braking and corner exit, while pillow ball upper mounts eliminate rubber deflection for steering precision at the adhesion limit. Monotube construction resists fade through extended race sessions. For WRX STI owners who are building a dedicated competition car and need Cusco coilovers with zero-compromise race valving, the Sport R is the right foundation.
Features
- 24-Level adjustable rebound damping (1-Way)
- Monotube shock absorber with high-pressure nitrogen
- Inverted front struts on MacPherson applications
- Pillow ball upper mounts
- Full-length adjustable threaded cases
- Race/competition specification
- Made in Japan
Specifications
| Part Number | 6A1 64R CP |
| Part Name | Cusco Sport R Coilovers |
| Vehicle | 2015-2021 Subaru WRX STI |
| Chassis Code | VAF |
| Engine | EJ25T |
| Drivetrain | AWD |
| Damping Adjustment | 1-Way (24 levels) |
| Ride-Height Adjustable | Yes |
| Spring Rate - Front | 14 Kg/mm |
| Spring Rate - Rear | 16 Kg/mm |
| Camber Plates - Front | Yes (Pillow Ball) |
| Camber Plates - Rear | No |
| Notes | WRX STI 4-door sedan; race/competition spec |
Vehicle Fitment
- 2015 Subaru WRX STI (VAF)
- 2016 Subaru WRX STI (VAF)
- 2017 Subaru WRX STI (VAF)
- 2018 Subaru WRX STI (VAF)
- 2019 Subaru WRX STI (VAF)
- 2020 Subaru WRX STI (VAF)
- 2021 Subaru WRX STI (VAF)
