Lifting or leveling a 2002-2006 GMC Envoy XL changes what the dampers have to do. The Bilstein B8 shocks are built for that taller stance and stay composed on rough ground.

The B8 5100 is Bilstein's direct fit monotube shock for lifted trucks and SUVs. Its velocity sensitive, digressive piston gives consistent, fade-free damping, and each shock is tuned for its application.

Bilstein has built suspension in Germany since 1954, and supplies the same engineering to manufacturers as original equipment. The build quality is the reason these outlast what they replace, and they are covered by a limited lifetime warranty.

Features

  • 46mm monotube design ensures consistent, fade-free performance in all conditions
  • Patented digressive valving instantly reacts to changing surface conditions
  • Vehicle specific tuning
Specifications
Part Number 24-267021
Part Name Shock Absorber
Vehicle 2002-2006 GMC Envoy XL
UPC 651860804347
Rear Lift Height 0 - 1 in.
Body Design Smooth Body (Non-Coilover)
Body Diameter (ID) 46 mm
Boot Included Black Bellows
Collapsed Length 14.63 in. (371.5 mm)
Damping Adjustable No
Extended Length 23.30 in. (591.7 mm)
Finish Zinc Plated
Internal Design Monotube
Lower Mount Type Eye 12.9 mm
Reservoir No
Segment Light Truck
Series B8 5100
Spring Seat Included No
Upper Mount Type Eye 12.9 mm
Quantity Sold Individually
Stroke 8.67 in. (220.2mm)
Piston Diameter 46mm
Shaft Diameter 14mm
Notes -

Vehicle fitment

This product fits the vehicles listed below.

YearMakeModelNotes
2002GMCEnvoy XL
2003GMCEnvoy XL
2004GMCEnvoy XL
2005GMCEnvoy XL
2006GMCEnvoy XL
