Product Details
Lifting or leveling a 2002-2006 Chevrolet Trailblazer EXT changes what the dampers have to do. The Bilstein B8 shocks are built for that taller stance and stay composed on rough ground.
Bilstein invented the monotube gas damper and has been building suspension in Germany since 1954. Every unit is built to the same standard the company supplies to the manufacturers themselves, and it is backed by a limited lifetime warranty.
Features
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Patented digressive valving instantly reacts to changing surface conditions
- Vehicle specific tuning
Specifications
| Part Number | 24-267021 |
| Part Name | Shock Absorber |
| Vehicle | 2002-2006 Chevrolet Trailblazer EXT |
| Drivetrain | 4WD |
| UPC | 651860804347 |
| Rear Lift Height | 0 - 1 in. |
| Body Design | Smooth Body (Non-Coilover) |
| Body Diameter (ID) | 46 mm |
| Boot Included | Black Bellows |
| Collapsed Length | 14.63 in. (371.5 mm) |
| Damping Adjustable | No |
| Extended Length | 23.30 in. (591.7 mm) |
| Finish | Zinc Plated |
| Internal Design | Monotube |
| Lower Mount Type | Eye 12.9 mm |
| Reservoir | No |
| Segment | Light Truck |
| Series | B8 5100 |
| Spring Seat Included | No |
| Upper Mount Type | Eye 12.9 mm |
| Quantity | Sold Individually |
Vehicle Fitment
- 2002 Chevrolet Trailblazer EXT
- 2003 Chevrolet Trailblazer EXT
- 2004 Chevrolet Trailblazer EXT
- 2005 Chevrolet Trailblazer EXT
- 2006 Chevrolet Trailblazer EXT
