Product Details

The Bilstein B6 shock absorber is sold for custom and motorsport builds. There is no vehicle lookup here: you select on dimension, mounting, and the damping you want.

The B6 Performance is a performance upgrade over the factory damper that works with the factory springs. Valving is set for each application, and every damper is tested to meet or exceed original equipment standards.

Inside is Bilstein's monotube design, gas and oil separated by a floating piston. That is what keeps the damping honest when the surface turns rough and the temperature climbs.

Features

  • Bilstein gas-pressure technology
  • Optimum grip and enhanced lane stability in day to day and extreme situations
  • Improved safety and performance without the requirement of new springs (use of series spring possible)
Specifications
Part Number 24-245685
Part Name Shock Absorber
UPC 651860774169
Boot Included Blue Straight
Damping Adjustable No
Finish Yellow Paint
Internal Design Monotube
Lower Mount Type Eye 12.1 mm
Reservoir No
Segment Tuning
Series B6 Performance
Spring Seat Included No
Upper Mount Type Eye 12.1 mm
Quantity Sold Individually
Collapsed Length 18.40 in.
Extended Length 25.40 in.
