Product Details
Bilstein AK Series Shock Absorbers for the 1980-1990 Cadillac Fleetwood are designed for motorsports applications that require the use of the OE mounting components. Each Shock Absorber features a monotube design with steel spring valve discs for consistent, fade free performance and superior durability. AK Series Shock Absorbers are ideal for racers who demand reliable performance that also meets their sanctioning body's mounting requirements.
Standard Features
- Monotube design ensures consistent, fade-free performance in all conditions
- Direct fit (OE) mounting design
- Race-winning valvings for optimum weight transfer, feel, and grip in various track conditions
Specifications
| Part Number | 24-291699 |
| Part Name | Shock Absorber |
| Vehicle | 1980-1990 Cadillac Fleetwood |
| UPC | 651860839318 |
| Body Design | Stock Mount Smooth Body |
| Body Diameter (ID) | 46 mm |
| Body Material | Steel |
| Boot Included | Blue Straight |
| Collapsed Length | 13.11 in. |
| Collapsed Length | 333.0 mm |
| Compression @ 0.26m/s | 630 |
| Damping Adjustable | No |
| Extended Length | 20.28 in. |
| Extended Length | 515.0 mm |
| Finish | Yellow Paint |
| Internal Design | Monotube |
| Lower Mount Type | Cantilever |
| Piston Type | Linear |
| Rebound @ 0.26m/s | 1130 |
| Segment | Motorsports |
| Series | AK Series |
| Spring Seat Included | No |
| Upper Mount Type | Bar Pin |
| Valving Identifier | 254/141 |
| Notes | Without Self-Leveling Suspension |
Vehicle Fitment
- 1980 Cadillac Fleetwood
- 1981 Cadillac Fleetwood
- 1982 Cadillac Fleetwood
- 1983 Cadillac Fleetwood
- 1984 Cadillac Fleetwood
- 1985 Cadillac Fleetwood
- 1986 Cadillac Fleetwood
- 1987 Cadillac Fleetwood
- 1988 Cadillac Fleetwood
- 1989 Cadillac Fleetwood
- 1990 Cadillac Fleetwood
