Product Details
BC Racing DS Series Coilovers for the 1979-1989 Ford Mustang Foxbody blend street-tuned ride quality with track-ready adjustability, giving you more body control than any OEM damper without the harshness of a pure race kit. Every kit is extensively tested on the Mustang Foxbody chassis and refined until it balances ride quality with performance — the reason Mustang Foxbody coilovers from BC Racing are the best-selling adjustable kits in their segment worldwide.
DS Series kits pair a mono-tube damper with BC's proprietary digressive piston design — increased low-speed damping for flat corner entry, compliant high-speed response over expansion joints and potholes. The finished shock body is silver, visually distinct from the BR Series, and ride height is adjustable independent of spring preload. Where BC Racing separates itself is tuning philosophy: every off-the-shelf spring rate and damper setup is chosen to stay comfortable on daily roads while still delivering real performance at the track. If you want something different, Swift Springs, custom rates, and custom valving are all options at checkout — BC will match the valving of the dampers to whatever springs you pick, something most brands don't offer outside their flagship race lineup.
BC Racing's reputation in the aftermarket suspension world is built on four things: competitive pricing that beats the rest of the fully-adjustable market, customization depth that rivals the top-tier race brands, long-term reliability earned over 20 years of production, and a rebuildable design that keeps the same set of dampers serving you through multiple builds. These Mustang Foxbody coilovers arrive tuned for the Mustang Foxbody chassis and ready to bolt in — no break-in period, no guessing at setup. Every kit ships with a 2-year manufacturer warranty, lifetime access to BC service parts (pistons, seals, shafts — no unit replacement required when it's time for a rebuild), and in-house tech support from both BC Racing and the Springrates team.
Features
- 30-level simultaneous compression/rebound damping adjuster
- Mono-tube damper with BC's proprietary digressive piston
- Silver satin-chrome finished shock body (visually distinct from the BR Series)
- Ride height adjustable independent of spring preload
- Upper mount hardware varies by chassis — camber plates, pillowball, or reused OEM mounts. See the Specifications table for what's included on your kit.
- Swift Spring and custom spring rate upgrades available at checkout
- Custom damper valving paired with custom spring rates on request
- Fully rebuildable — replacement parts available from BC for the life of the shock
- 2-year manufacturer warranty against defects
Specifications
| Part Number | E-46-DS |
| Part Name | DS Series Coilovers |
| Vehicle | 1979-1989 Ford Mustang Foxbody |
| Drivetrain | RWD |
| Damping Adjustment | 1-Way (30 levels) |
| Ride-Height Adjustable | Yes |
| Spring Rate - Front | 6 kg/mm |
| Spring Rate - Rear | 190 kg/mm |
| Spring Size - Front | 62-220-6K |
| Spring Size - Rear | 100-62-190K |
| Swift Springs - Front | 62-203-X |
| Camber Plates - Front | Not Applicable |
| Camber Plates - Rear | Not Applicable |
| Suspension Design - Front | True Coilover |
| Suspension Design - Rear | Divorced |
| Notes | Fits 20mm Knuckle Only |
Vehicle Fitment
- 1979 Ford Mustang Foxbody RWD
- 1980 Ford Mustang Foxbody RWD
- 1981 Ford Mustang Foxbody RWD
- 1982 Ford Mustang Foxbody RWD
- 1983 Ford Mustang Foxbody RWD
- 1984 Ford Mustang Foxbody RWD
- 1985 Ford Mustang Foxbody RWD
- 1986 Ford Mustang Foxbody RWD
- 1987 Ford Mustang Foxbody RWD
- 1988 Ford Mustang Foxbody RWD
- 1989 Ford Mustang Foxbody RWD
