Product Details
The Bilstein B8 8100 shock absorber is sold for custom and motorsport builds, here at 14.72 in. collapsed. There is no vehicle lookup here: you select on dimension, mounting, and the damping you want.
Built in Germany to the standard that made the name, and backed by Bilstein's limited lifetime warranty. Consistency is the point: a damper that behaves the same on the tenth lap as the first.
Discontinued - Final Sale
Bilstein has discontinued this part. We are selling the remaining stock and it will not be restocked once it is gone. Because of that, all sales on this item are final: it cannot be returned or exchanged.
Features
- Dual tube external bypass offers position sensitive damping with independent adjustment for rebound and compression
- Incremental flow adjuster offers finite and incremental changes in damping force for precise adjustments
- 60mm large bore hard anodized aluminum piston offers a greater range of damping control and delivers exceptional long-term durability
Specifications
| Part Number | 25-284591 |
| Part Name | Shock Absorber |
| UPC | 651860845913 |
| Adjustable Damping | Double Adjustable - Compression and Rebound |
| Body Design | Bypass Body (Non-Coilover) |
| Boot Included | No |
| Collapsed Length | 14.72 in. (374mm) |
| Extended Length | 24.09 in. (612mm) |
| Finish | Zinc Plated |
| Internal Design | Monotube |
| Lower Mount Type | Eye 19.3mm |
| Piston Diameter | 60mm |
| Vehicle Placement | Rear Right |
| Reservoir | Yes |
| Segment | Light Truck |
| Series | B8 8100 (Bypass) |
| Shaft Diameter | 18mm |
| Spring Seat Included | No |
| Upper Mount Type | Stem |
