Product Details
The Bilstein B8 shocks are built for a 2011-2026 GMC Sierra 3500 HD (GMT900/K2XX/T1XX) that has been lifted or leveled, valved for the taller ride height rather than fighting it.
Inside is Bilstein's monotube design, with the gas and oil separated by a floating piston. That keeps damping consistent when the road turns rough and the unit gets hot, where a lesser damper would go soft.
Features
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Patented digressive valving instantly reacts to changing surface conditions
- Vehicle specific tuning
Specifications
| Part Number | 24-218030 |
| Part Name | Shock Absorber |
| UPC | 651860697086 |
| Vehicle | 2011-2026 GMC Sierra 3500 HD |
| Chassis Code | GMT900/K2XX/T1XX |
| Drivetrain | RWD/4WD |
| Adjustable Damping | Non-Adjustable |
| Body Design | Smooth Body (Non-Coilover) |
| Boot Included | Black Bellows |
| Collapsed Length | 18.17 in. (461.5mm) |
| Extended Length | 29.92 in. (760mm) |
| Finish | Zinc Plated |
| Internal Design | Monotube |
| Lower Mount Type | Eye 14.4mm |
| Piston Diameter | 46mm |
| Vehicle Placement | Rear |
| Reservoir | No |
| Segment | Light Truck |
| Series | B8 5100 |
| Shaft Diameter | 14mm |
| Spring Seat Included | No |
| Stroke/Travel Length | 11.75 in. (298.5mm) |
| Upper Mount Type | Eye 14.4mm |
| Notes | Fits Vehicles With 3-4" Rear Lift |
