Product Details
This Whiteline Rear Spring Eye and Shackle Bushing Kit fits the 1972-1977 Pontiac Ventura. This part is for the rear of the vehicle. Included: 12 bushings, 2 tubes, and grease. Part number W73822.
On a leaf-sprung vehicle the spring eyes and shackles pivot on bushings, and they take the movement every time the axle moves. Worn rubber lets the axle shift and clunk, and heavy loads speed that up. The polyurethane used here deflects much less than the original rubber under the same load.
Whiteline rates the install as moderate and lists about 2 hours. Plan on a wheel alignment afterward. Other Whiteline parts we list for the Ventura: Ball Joint Boot Kit and Front Upper and Lower Control Arm Bushing Kit.
Features
- Install guide: Step-by-step installation instructions come with it.
- Self-lubricating: Internal grease reservoirs keep the bushing lubricated as it works.
- Grease: Supplied with molybdenum disulfide grease for extended service life.
- Bushing material: Polyurethane bushings flex far less than rubber ones.
- Bushing compound: Oil, grease, ozone, and weather do not break down the synthetic elastomer used in the bushings.
Specifications
| Part Number | W73822 |
| Part Name | Leaf Spring Bushings |
| Vehicle | 1972-1977 Pontiac Ventura |
| Drivetrain | RWD |
| Chassis Code | X-Body |
| Bushing Color | Black |
| Bushing Inside Diameter | 14.2 mm |
| Bushing Length | 49 mm |
| Bushing Material | Polyurethane |
| Bushing Outside Diameter | 40.8 mm |
| Durometer | 85 |
| Grade Type | Regular |
| Installation Difficulty | Moderate |
| Installation Time (hrs) | 2 |
| Kit Contents | 12 Bushings, 2 Tubes, Grease |
| Vehicle Placement | Rear |
| Wheel Alignment Required | Yes |
| Notes | - |
