Product Details
The ISR Performance Pro Series Coilovers for the 1986-1991 Mazda RX-7 (FC3S) drop your ride height, sharpen turn-in response, and pull the chassis together without beating you up on the commute. Built around a monotube shock body with 32 clicks of rebound adjustment, these Mazda RX-7 coilovers give you the range to set the car up softly for daily driving and crank it back down for a canyon run or track weekend.
Every Pro Series Coilovers kit ships with pillowball front upper mounts for precise camber control, high-end Japanese internal bearings, and a spanner wrench to tune ride height at home. Whether you're running the FC3S RX-7 at a local grassroots drift event, carving through back roads, or simply wanting a cleaner stance and tighter feel, ISR Pro coilovers deliver factory-quality fitment with aftermarket performance.
Features
- 32-way adjustable damping for precise rebound tuning
- Monotube shock design for consistent fade-free performance
- High-end Japanese internal bearings for long service life
- Pillowball front upper mounts with integrated camber adjustment
- Complete kit including spanner wrench and mounting hardware
Specifications
| Part Number | IS-PRO-FC3S |
| Part Name | ISR Performance Pro Series Coilovers |
| Vehicle | 1986-1991 Mazda RX-7 |
| Chassis Code | FC3S |
| Drivetrain | RWD |
| Damping Adjustment | 32-Way |
| Ride-Height Adjustable | Yes |
| Spring Rate - Front | 8 Kg/mm |
| Spring Rate - Rear | 6 Kg/mm |
| Suspension Design - Front | True Coilover |
| Suspension Design - Rear | True Coilover |
| Top Mounts - Front | Pillowball |
| Top Mounts - Rear | Rubber |
Vehicle Fitment
- 1986 Mazda RX-7 RWD (FC3S)
- 1987 Mazda RX-7 RWD (FC3S)
- 1988 Mazda RX-7 RWD (FC3S)
- 1989 Mazda RX-7 RWD (FC3S)
- 1990 Mazda RX-7 RWD (FC3S)
- 1991 Mazda RX-7 RWD (FC3S)
