Product Details
The Cusco Sport R Coilovers for the 2005-2011 Toyota Yaris (NCP91) deliver race-ready suspension for the ultralight subcompact with monotube construction, inverted front struts, and competition-specification damper valving. The front-biased 12 Kg/mm front and 7 Kg/mm rear spring rates with 24-level rebound control maximize FWD traction for grassroots racing.
The NCP91 Yaris is a proven platform in JDM one-make racing and lightweight time attack, where its sub-1,100 kg curb weight rewards stiff, well-damped suspension. The front-heavy spring split loads the front tires for maximum traction under the 1NZ-FE's output, extracting every tenth through corner exit. For Toyota Yaris racers who need Cusco coilovers with competition valving that exploit the platform's featherweight advantage, the Sport R is purpose-built for the podium.
Features
- 24-Level adjustable rebound damping (1-Way)
- Monotube shock absorber with high-pressure nitrogen
- Inverted front struts on MacPherson applications
- Pillow ball upper mounts
- Full-length adjustable threaded cases
- Race/competition specification
- Made in Japan
Specifications
| Part Number | 901 64R CB |
| Part Name | Cusco Sport R Coilovers |
| Vehicle | 2005-2011 Toyota Yaris |
| Chassis Code | NCP91 |
| Engine | 1NZ-FE (1.5L) |
| Drivetrain | FWD |
| Damping Adjustment | 1-Way (24 levels) |
| Ride-Height Adjustable | Yes |
| Spring Rate - Front | 12 Kg/mm |
| Spring Rate - Rear | 7 Kg/mm |
| Camber Plates - Front | No |
| Camber Plates - Rear | No |
| Notes | Reuses OE upper mounts |
Vehicle Fitment
- 2005 Toyota Yaris (NCP91)
- 2006 Toyota Yaris (NCP91)
- 2007 Toyota Yaris (NCP91)
- 2008 Toyota Yaris (NCP91)
- 2009 Toyota Yaris (NCP91)
- 2010 Toyota Yaris (NCP91)
- 2011 Toyota Yaris (NCP91)
