Product Details
The Bilstein Bilstein shock absorber is sold for custom and motorsport builds, here at 12.09 in. collapsed. There is no vehicle lookup here: you select on dimension, mounting, and the damping you want.
Built in Germany to the standard that made the name, and backed by Bilstein's limited lifetime warranty. Consistency is the point: a damper that behaves the same on the tenth lap as the first.
Features
- 46mm extruded aluminum threaded body improves durability and heat dissipation
- Dual-zone gas bulb decreases gas pressure while increasing grip levels
- Optimized floating piston improves driver feel and response
- Single Adjustable - Rebound
Specifications
| Part Number | 33-314686 |
| Part Name | Shock Absorber |
| UPC | 651860874005 |
| Adjustment Type | 1-Way |
| Body Design | Threaded Body Large Bulb Screw Top (Coilover) |
| Body Diameter (ID) | 46 mm |
| Body Material | Aluminum |
| Boot Included | No |
| Collapsed Length | 12.09 in. (307.0 mm) |
| Damping Adjustable | Yes |
| Extended Length | 16.50 in. (419.0 mm) |
| Finish | Clear Anodized |
| Internal Design | Monotube |
| Lower Mount Type | Sold Separately |
| Piston Type | Sold Separately |
| Segment | Motorsports |
| Series | XVA Series |
| Spring Seat Included | No |
| Upper Mount Type | Sold Separately |
| Valving Identifier | Dry Kit (No Valving) |
| Quantity | Sold Individually |
