Product Details
The Bilstein B8 shocks are built for a 2004-2015 Nissan TITAN that has been lifted or leveled, valved for the taller ride height rather than fighting it.
Inside is Bilstein's monotube design, with the gas and oil separated by a floating piston. That keeps damping consistent when the road turns rough and the unit gets hot, where a lesser damper would go soft.
Features
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Patented digressive valving instantly reacts to changing surface conditions
- Vehicle specific tuning
Specifications
| Part Number | 24-186766 |
| Part Name | Shock Absorber |
| Vehicle | 2004-2015 Nissan TITAN |
| Drivetrain | 4WD |
| UPC | 651860568911 |
| Rear Lift Height | 0 - 1 in. |
| Body Design | Smooth Body (Non-Coilover) |
| Body Diameter (ID) | 46 mm |
| Boot Included | Black Bellows |
| Collapsed Length | 15.79 in. (401.0 mm) |
| Damping Adjustable | No |
| Extended Length | 25.00 in. (635.0 mm) |
| Finish | Zinc Plated |
| Internal Design | Monotube |
| Lower Mount Type | Eye 14 mm |
| Reservoir | No |
| Segment | Light Truck |
| Series | B8 5100 |
| Spring Seat Included | No |
| Upper Mount Type | Eye 14 mm |
| Quantity | Sold Individually |
Vehicle Fitment
- 2004 Nissan TITAN 4WD
- 2005 Nissan TITAN 4WD
- 2006 Nissan TITAN 4WD
- 2007 Nissan TITAN 4WD
- 2008 Nissan TITAN 4WD
- 2009 Nissan TITAN 4WD
- 2010 Nissan TITAN 4WD
- 2011 Nissan TITAN 4WD
- 2012 Nissan TITAN 4WD
- 2013 Nissan TITAN 4WD
- 2014 Nissan TITAN 4WD
- 2015 Nissan TITAN 4WD
