Product Details
The Bilstein B8 shocks are built for a 1993 Jeep Grand Wagoneer (ZJ) that has been lifted or leveled, valved for the taller ride height rather than fighting it.
Inside is Bilstein's monotube design, with the gas and oil separated by a floating piston. That keeps damping consistent when the road turns rough and the unit gets hot, where a lesser damper would go soft.
Features
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Patented digressive valving instantly reacts to changing surface conditions
- Vehicle specific tuning
Specifications
| Part Number | 24-185943 |
| Part Name | Shock Absorber |
| Vehicle | 1993 Jeep Grand Wagoneer |
| Chassis Code | ZJ |
| Drivetrain | 4WD |
| UPC | 651860649986 |
| Front Lift Height | 5 - 6 in. |
| Body Design | Smooth Body (Non-Coilover) |
| Body Diameter (ID) | 46 mm |
| Boot Included | Black Bellows |
| Collapsed Length | 16.97 in. (431.0 mm) |
| Damping Adjustable | No |
| Extended Length | 28.44 in. (722.5 mm) |
| Finish | Zinc Plated |
| Internal Design | Monotube |
| Lower Mount Type | Bar Pin |
| Reservoir | No |
| Segment | Light Truck |
| Series | B8 5100 |
| Spring Seat Included | No |
| Upper Mount Type | Stem |
| Quantity | Sold Individually |
| Notes | With Long Arm Lift Kit |
Vehicle Fitment
- 1993 Jeep Grand Wagoneer (ZJ)
