Product Details
The Bilstein AS2 Series shock absorber is sold for custom and motorsport builds, here at 21.39 in. extended. There is no vehicle lookup here: you select on dimension, mounting, and the damping you want.
Inside is Bilstein's monotube design, gas and oil separated by a floating piston. That is what keeps the damping honest when the surface turns rough and the temperature climbs.
Features
- 46mm lightweight extruded aluminum body for superior heat dissipation
- Fine thread body provides precise adjustments in coilover applications
- Single and double adjustable shaft options available
Specifications
| Part Number | 33-343495 |
| Part Name | Shock Absorber |
| UPC | 651860923048 |
| Adjustment Type | 1-Way |
| Body Design | Threaded Body Screw Top (Coilover) |
| Body Diameter (ID) | 46 mm |
| Body Material | Aluminum |
| Boot Included | No |
| Collapsed Length | 14.24 in. (361.8 mm) |
| Damping Adjustable | Yes |
| Extended Length | 21.39 in. (543.4 mm) |
| Finish | Clear Anodized |
| Internal Design | Monotube |
| Lower Mount Type | 1/2 in. Heim |
| Piston Type | Sold Separately |
| Segment | Motorsports |
| Series | AS2 Series |
| Spring Seat Included | Yes |
| Upper Mount Type | 1/2 in. Heim |
| Valving Identifier | Dry Kit (No Valving) |
| Quantity | Sold Individually |
