Product Details
Bilstein shocks for the 1982-1986 Pontiac Bonneville, engineered and built in Germany to the standard that made the name.
Bilstein invented the monotube gas damper and has been building suspension in Germany since 1954. Every unit is built to the same standard the company supplies to the manufacturers themselves, and it is backed by a limited lifetime warranty.
Features
- Monotube design ensures consistent, fade-free performance in all conditions
- Direct fit (OE) mounting design
- Race-winning valvings for optimum weight transfer, feel, and grip in various track conditions
Specifications
| Part Number | 24-291699 |
| Part Name | Shock Absorber |
| Vehicle | 1982-1986 Pontiac Bonneville |
| Drivetrain | RWD |
| UPC | 651860839318 |
| Body Design | Stock Mount Smooth Body |
| Body Diameter (ID) | 46 mm |
| Body Material | Steel |
| Boot Included | Blue Straight |
| Collapsed Length | 13.11 in. (333.0 mm) |
| Compression @ 0.26m/s | 630 |
| Damping Adjustable | No |
| Extended Length | 20.28 in. (515.0 mm) |
| Finish | Yellow Paint |
| Internal Design | Monotube |
| Lower Mount Type | Cantilever |
| Piston Type | Linear |
| Rebound @ 0.26m/s | 1130 |
| Segment | Motorsports |
| Series | AK Series |
| Spring Seat Included | No |
| Upper Mount Type | Bar Pin |
| Valving Identifier | 254/141 |
| Quantity | Sold Individually |
| Notes | Without Self-Leveling Suspension |
Vehicle Fitment
- 1982 Pontiac Bonneville
- 1983 Pontiac Bonneville
- 1984 Pontiac Bonneville
- 1985 Pontiac Bonneville
- 1986 Pontiac Bonneville
