Product Details
The Bilstein AS2 Series shock absorber is a universal-fit part, chosen on collapsed and extended length rather than a year-make-model lookup. Fabricators, restorers, and race teams buy these to suit a custom setup.
Bilstein supplies suspension as original equipment to manufacturers worldwide and applies the same engineering here. Covered by a limited lifetime warranty.
Features
- 46mm lightweight extruded aluminum body for superior heat dissipation
- Fine thread body provides precise adjustments in coilover applications
- Single and double adjustable shaft options available
Specifications
| Part Number | 33-334066 |
| Part Name | Shock Absorber |
| UPC | 651860907284 |
| Adjustable Damping | Non-Adjustable |
| Body Design | Threaded Body Screw Top (Coilover) |
| Body Material | Aluminum |
| Boot Included | No |
| Collapsed Length | 12.78 in. (324.6mm) |
| Extended Length | 19.8 in. (502.9mm) |
| Finish | Clear Anodized |
| Internal Design | Monotube |
| Lower Mount Type | 1/2 in. Teflon Heim |
| Piston Diameter | 46mm |
| Piston Type | Linear |
| Vehicle Placement | Front Left |
| Segment | Motorsports |
| Series | AS2 Series |
| Shaft Diameter | 14mm |
| Spring Seat Included | Yes |
| Stroke/Travel Length | 7.02 in. (178.3mm) |
| Upper Mount Type | 1/2 in. Teflon Heim |
